Heavy Duty Rotary Disc Granulator with Scraper Device for Mineral Powder Balling

Welcome to our premium Disc Granulator (Pan Granulator) product page. This machine is a highly efficient and reliable piece of industrial equipment designed to convert various powder materials into uniform spherical granules. With its robust construction and stable performance, it is widely adopted in the fertilizer, metallurgy, and building materials industries.
Availability:
Inquire Add to Basket

Product Description

Working Principle

The Disc Granulator operates on a simple yet highly effective "snowball" principle. Driven by a motor and reducer, the large inclined disc rotates continuously. Raw powder materials are fed into the disc, where they are lifted by the friction between the material and the disc wall, and then fall back down under gravity. During this rolling process, a liquid binder or water is sprayed evenly. The continuous tumbling action causes the powder particles to stick together, gradually growing into uniform spherical granules. Built-in scraper blades prevent materials from sticking to the disc wall and ensure a smooth discharge.

Key Features & Advantages

  • High Granule Quality: Produces round, uniform, and high-strength granules with a high pass rate (up to 90%).

  • Heavy-Duty Construction: Reinforced disc structure with multiple layers of strengthening ribs ensures long service life and stable operation under heavy loads.

  • Flexible Adjustment: The disc angle and rotation speed can be adjusted to control the size of the granules according to specific requirements.

  • Anti-Sticking Design: Equipped with specialized scraper devices to prevent wall adhesion, ensuring continuous and smooth production.

  • Wide Applicability: Suitable for various materials including organic fertilizers, NPK compound fertilizers, iron ore powder, cement, and lime.

  • Low Energy Consumption & Easy Maintenance: Simple mechanical structure makes it easy to operate and maintain, saving both power and labor costs.

Wide Application Scope

  • Fertilizer Industry: Granulation of organic manure (chicken/cow manure), bio-fertilizer, and NPK compound fertilizers.

  • Metallurgy & Mining: Balling of iron ore concentrate, mineral powder, and metallurgical dust for blast furnace smelting.

  • Building Materials: Production of lightweight ceramsite, refractory materials, and cement clinker.

  • Chemical Industry: Granulation of catalyst carriers and various chemical powders.

Why Choose Us?

  • Factory Direct Supply: Competitive pricing without middlemen.

  • Customization Available: We can customize the disc diameter, capacity, and motor brand according to your specific production line needs.

  • Strict Quality Control: Every machine undergoes rigorous testing before delivery.

  • After-Sales Support: Professional engineers are available for overseas installation, commissioning, and training.

Inquiry & Contact

If you are looking for a reliable granulation solution for your production line, please feel free to contact us!
