Product Description
Yile Machinery is a specialist manufacturer of custom forged spiral bevel gears and matched gear sets. Engineered for high-torque, right-angle power transmission, our gears are designed for smooth, quiet, and reliable operation in the most demanding industrial and automotive applications.
Unlike straight bevel gears, the teeth on a spiral bevel gear are curved and oblique. This design provides several key advantages:
Higher Load Capacity: More than one tooth is in contact at any given time, allowing for greater load distribution.
Smoother & Quieter Operation: The gradual engagement of the curved teeth reduces vibration and noise significantly.
Greater Efficiency: Smooth meshing minimizes power loss through friction.
The longevity and strength of a spiral bevel gear begin with the right material and heat treatment.
Primary Material - Forged 20CrMnTi Alloy Steel:
We start with high-quality forged blanks of 20CrMnTi, a premier case-hardening steel. The forging process aligns the grain structure of the steel, providing superior strength and fatigue resistance compared to gears cut from bar stock.
Advanced Heat Treatment - Carburizing & Quenching:
To achieve the ideal combination of durability and toughness, the gears undergo a precise carburizing and quenching process. This creates:
A Hard, Wear-Resistant Surface: The gear teeth can withstand high contact stress and wear.
A Tough, Ductile Core: The core of the gear remains tough to absorb shock loads without fracturing.
Manufacturing high-quality spiral bevel gears requires specialized machinery and a meticulous process.
CNC Machining: The forged blank is precision-machined to its near-net shape.
5-Axis CNC Gear Cutting: Using advanced 5-axis CNC gear cutting machines (e.g., Gleason or Klingelnberg method), we generate the complex spiral tooth geometry with exceptional accuracy.
Heat Treatment: The gear undergoes the critical carburizing, quenching, and tempering cycle.
Hard Finishing & Lapping: To achieve the ultimate precision and smooth surface finish, the gear teeth are hard-finished by grinding. Following this, the gear and its matching pinion are lapped together as a matched set. This final process ensures a perfect contact pattern, guaranteeing quiet operation and long life.
Quality Assurance: Every gear set is inspected for dimensional accuracy and, most importantly, its tooth contact pattern is verified using marking compound to ensure it meets design specifications.
Our custom forged spiral bevel gears are essential components in:
Automotive Differentials (Cars, Trucks, Off-Road Vehicles)
Industrial Right-Angle Gearboxes
Agricultural Machinery (Tractors, Harvesters)
Machine Tools (e.g., Milling Heads)
Marine Propulsion Systems
Get a Quote for Your Custom Gear Set
Send us your technical drawings and specifications. We manufacture complete, performance-guaranteed spiral bevel gear and pinion sets.
